Roots blower conveying gas

The performance and system requirement of Roots blower

1.the impeller of Roots blower and lubrication system

1.1 Direction of turning:For the fan belt wheel (coupling), the counterclockwise on the left side as the positive direction;clockwise on the right side as the positive direction .All accessories of Roots blower including base, actuator, import and export of silencer, pressure gauge, safety valve, flexible joint, check valve, cushions, anchor bolt and its fittings, etc.

1.2 Using three impeller and linear spiral belt box body, two parallel axis with trefoil impeller, the impeller and elliptical hole surface inside the case and the remain small clearance between the impeller, which the impeller always keep the correct phase, by synchronous gear will not touch each other

1.3 The impeller is nodular cast ironQT500-7 and the axis is the NO.45 high quality carbon steel.Impeller type is complex,less leakage during operation.The axis in cold state,impeller diameter 0.04mm can be made again after heating , the hydraulic pressure to the fixed position slowly, operating at a high speed axis between the impeller and keep the interference of 0.01 mm, make it not loose leaf axis at high speed.

1.4 Roots blower synchronous gear adopts spur gear structure.

1.5 The one side axis of Roots blower adopts splash lubrication,another side axis adopts grease lubricantion. Adopting splash lubrication on both ends of the dual fuel tank's fan.

1.6 Roots blower cooling way is water cooling /air cooling ,the transmission way is drive/pulley, blower fan for single stage.

1.7 Roots blower fits in motor on institutional characteristics, working conditions, environmental conditions, the motor insulation class is F, protection class is IP54, 380 v, 50 hz.

Roots blower conveying gas Hongli Shengde Environment Science and Technology Co., LTD., is a high-tech enterprise integrating production and R&D.

Now the company is member unit of China Association of Environmental Protection Industry (CAEPI), council unit of Roots blower conveying gas Association of Environmental Protection Industry, and teaching practice base of Qingdao University of Science & Technology. We have long-term cooperation with Tsinghua University, University of Shanghai for Science and Technology and other famous domestic universities and institutes. We have obtained multiple national utility model patents and passed ISO9001: 2008 quality management system certification. We have high non-standard design, manufacture and service ability with comprehensive testing and detective equipments, complete product specifications reliable and stable quality and customization support. The solid-liquid separating machine developed jointly with Jilin Agriculture Committee has been widely used and promoted.

With the constant development and innovation, our products win a broad market throughout China and have been export to European, American and Southeast Asia regions.

i, High-pressure Roots Blower Low noise
Roots blower conveying gas with adoption of helical tri-lobe roots rotors and the discharge port of special geometry, the airflow noise is much lower compared to typical straight-lobe roots blower. The noise level can be reduced by 8db in the band of low frequency; hence the noise in the surroundings of blower can be significantly improved.

JHJHBJH
ii, High adiabatic efficiency
High-pressure Roots Blower with design of helical tri-lobe roots rotors, Roots blower conveying gas the airflow pulsation is less and the air streamline would be more stable. Therefore the fluctuation in airflow is less and then the energy waste can be reduced. Additionally, the instantaneous backflow of discharge is lower by the design of special discharge port. Compared to straight-lobe roots blower, the adiabatic efficiency can be raised up to 20%.

HJJHBJH
iii, High-pressure Roots Blower Super Energy saving
Compared to the typicalRoots blower conveying gas under the same operation conditions of discharge pressure and airflow volume, the power consumption of helical tri-lobe roots blower will be lower by 20.
